HT-208
High precision digital multimeter clip-on meter Clamp ammeter
feature
--Pocket-size clamp meter
--6000 counts
--Sample Rate is 2 times/sec
--AC current measuring capability up to 1000Amps
--True RMS measurement on AC mode
--Inrush Current Measurement
--NCV (Non-Contacted Voltage detection)
--Data hold
--Auto Power Off (15 min)
--Backlight
--Auto Ranging
--Low Power Indication
--EN61010 600V CAT III
| specifications | range | accuracy | ||
| HT208A | HT208B | HT208D | ||
| DC Voltage | 6V/60V/600V/1000V | ±(1.0%+3) | ±(1.0%+3) | ±(1.0%+3) |
| AC Voltage | 6V/60V/600V/750V | ±(1.2%+3) | ±(1.2%+3) | ±(1.2%+3) |
| DC Current | 60A/600A/1000A | ±(3.0%+5) | ||
| AC Current | 60A/600A/1000A | ±(3.0%+5) | ±(3.0%+5) | ±(3.0%+5) |
| Resistance | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ | ±(1.0%+3) | ±(1.0%+3) | ±(1.0%+3) |
| Capacitance | 60nF/600nF/6uF/60uF/600uF/6mF/60mF | ±(4.0%+3) | ±(4.0%+3) | ±(4.0%+3) |
| 100mF | ±(5.0%+5) | ±(5.0%+5) | ±(5.0%+5) | |
| Frequency | 10Hz/100Hz/1kHz/10kHz/ 100kHz/1MHz/10MHz | ±(1.0%+3) | ±(1.0%+3) | ±(1.0%+3) ±(1.0%+2) |
| Duty | 1%~99% | ±(1.0%+2) | ±(1.0%+2) | ±(1.0%+3) |
| Temperature(ºC/°F) | -40ºC~1000ºC | ±(1.0%+3) | ±(1.0%+3) | ±(1.0%+3) |
| -40°F~1832°F | ±(1.0%+3) | ±(1.0%+3) | ||
| Counters | 6000 | 6000 | 6000 | |
| Auto/manual range | √ | √ | √ | |
| Bargraph | √ | √ | ||
| NCV (LED and Buzz) | √ | √ | √ | |
| Diode | √ | √ | √ | |
| Continuity (LED and Buzz) | √ | √ | √ | |
| MAX/MIN hold | √ | √ | √ | |
| Data hold | √ | √ | √ | |
| True RMS | √ | √ | √ | |
| AC bandwidth | 1KHZ | 1KHZ | 1KHZ | |
| Low battery indication | √ | √ | √ | |
| Auto power off | √ | √ | √ | |
| Double color backlight | √ | √ | √ | |
| Flashlight | √ | √ | √ | |
| LPF | √ | √ | ||
| V-Loz | √ | √ | ||
