Summary

Water Salinity Sensor adopts the world's leading four-electrode technology, RS485 digital interface, supports MODBUS protocol, and is environmentally friendly design. The new generation of salinity sensor not only has higher accuracy, wider measuring range and stronger stability. It also has unique advantages of large quantity: first, it completely solves the polarization problem in high conductivity test; second, it solves the problem of inaccurate reading caused by electrode contamination.
IP68 Digital Water Quality Sensor RS485 Conductivity Salinity Temperature Electrode


Features of salinity sensor

  1. 0~80ppt, accuracy ±1ppt

  2. RS485 output, support Modbus, and open communication protocol

  3. 0~50ºC, protection class IP68, maximum pressure 6bar

  4. Will not be polarized and can be used continuously online5

  5. The measuring range is extremely wide and the application is wider6

  6. Very resistant to pollution and strong anti-interference ability

  7. The measurement is very stable and the accuracy is higher



Product parameters

Name Parameter
ModelDG-Y520-A
Range0~80 ppt
Response time<10 sec
IP ratingIP68
Salinity accuracy±1 ppt
Electrode materialNickel+316L/Ta2
Body MaterialPEEK
Operating Temperature0 ~ 50ºC
OutputModbus RS-485
Power Consumption      DC 5~12V ,I<50mA
Temperature Sensor NTC
Dimension   Φ22*210 mm
Cable length10m (default),custom length available
CalibrationOne point or two-points
