| Specification | Type | 1 Phase 2 Wires Din Rail Meter with IHD |
| Reference Voltage | 230V | |
| Current | 5(80) A | |
| Accuracy Class | 1.0 | |
| Related Frequency | 50Hz | |
| Standard | IEC62052-11, IEC62053-21, IEC62055-41 | |
| Impulse Constant | 1000imp/kWh | |
| Display | Without LCD | |
| Power Consumption | <10VA/2W | |
| Temperature Range | -20~70ºC | |
| Annual Average Humidity Value | 75% | |
| Maximal Humidity Value | 95% | |
| Case,Base & Terminal | PBT+15% GF | |
| Hook | ABS | |
| Dimension | 141.6*49*87mm | |
| UIU | X929013 | |
| Voltage | 240V | |
| Related Frequency | 50Hz | |
| Communication Protocol | DLMS/COSEM (IEC62056) | |
| Starting Current | 40mA | |
| Temperature Range | -20~70ºC | |
| Limit Working Temperature | -30~780ºC |
