M12 DC PNP Nc output inductive proximity sensor, sensor distance is 4mm

LJA12M-5P2-H      M12  DC PNP Nc output  inductive sensor with 4 mm sensor distanceDescriptionC-lin Brand proximity sensor switch is a displacement sensor with switching output, output mode have NPN, PNP, NO, NC and relay etc, it can be detect metal (such as iron, steel, copper) object, plastic, glass, w

Featured Products

LJA12M-5P2-H      M12  DC PNP Nc output  inductive sensor with 4 mm sensor distance
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance

Description

C-lin Brand proximity sensor switch is a displacement sensor with switching output, output mode have NPN, PNP, NO, NC and relay etc, it can be detect metal (such as iron, steel, copper) object, plastic, glass, wooden, water, paper, magnetic etc. transparent or opaque objects, can be connect with PLC, servo controller, frequency inverter, counter, controllers to achieve the purpose of automatic signal input control. It is widely used in the field of machinery, textile, light industry, papermaking, printing, packing industries. Meanwhile as per to market demand, we developed C series high class proximity sensor and normal class proximity sensor.
Inductive type Proximity Sensor can detect metal object ( such as Iron, Steel, Copper etc)
Capacitive type proximity sensor can detect any object (such as glass, metal,water, oil, paper etc.)

Product Features

Stable performance
Inside element with SMT process technology
With stable performance and reliable quality

Circuit protection
Reverse polarity protection to avoid un-correct wiring

Safety and reliable
Adopt imported emitter and receiver, high accuracy of sensing distance.
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance

Model meanings

M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance

Specifications
ModelLJA8 SeriesLJA12 Series
Installation methodEmbeddableNon-embeddableEmbeddableNon-embeddable
DC TypeNPNNOLJA/B8-1.5N1LJA/B8M-2N1LJA/B12-2N1LJA/B12M-5N1
NCLJA/B8-1.5N2LJA/B8M-2N2LJA/B12-2N2LJA/B12M-5N2
NO+NC  LJA/B12-2N4LJA/B12M-5N4
PNPNOLJA/B8-1.5P1LJA/B8M-2P1LJA/B12-2P1LJA/B12M-5P1
NCLJA/B8-1.5P2LJA/B8M-2P2LJA/B12-2P2LJA/B12M-5P2
NO+NC  LJA/B12-2P4LJA/B12M-5P4
2-wireNOLJA/B8-1.5D1LJA/B8M-2D1LJA/B12-2D1LJA/B12M-5D1
NCLJA/B8-1.5D2LJA/B8M-2D2LJA/B12-2D2LJA/B12M-5D2
AC Type2-wireNOLJA/B8-1.5A1LJA/B8M-2A1LJA/B12-2A1LJA/B12M-5A1
NCLJA/B8-1.5A2LJA/B8M-2A2LJA/B12-2A2LJA/B12M-5A2
Sensing distance1.5mm±10%2mm±10%2mm±10%5mm±10%
Response frequencyDC1.5KHz0.8KHz0.8KHz0.4KHz
AC25Hz25Hz

ModelLJA18 SeriesLJA30 Series
Installation methodEmbeddableNon-embeddableEmbeddableNon-embeddable
DC TypeNPNNOLJA/B18-5N1LJA/B18M-10N1LJA/B30-10N1LJA/B30M-18N1
NCLJA/B18-5N2LJA/B18M-10N2LJA/B30-10N2LJA/B30M-18N2
NO+NCLJA/B18-5N4LJA/B18M-10N4LJA/B30-10N4LJA/B30M-18N4
PNPNOLJA/B18-5P1LJA/B18M-10P1LJA/B30-10P1LJA/B30M-18P1
NCLJA/B18-5P2LJA/B18M-10P2LJA/B30-10P2LJA/B30M-18P2
NO+NCLJA/B18-5P4LJA/B18M-10P4LJA/B30-10P4LJA/B30M-18P4
2-wireNOLJA/B18-5D1LJA/B18M-10D1LJA/B30-10D1LJA/B30M-18D1
NCLJA/B18-5D2LJA/B18M-10D2LJA/B30-10D2LJA/B30M-18D2
AC Type2-wireNOLJA/B18-5A1LJA/B18M-10A1LJA/B30-10A1LJA/B30M-18A1
NCLJA/B18-5A2LJA/B18M-10A2LJA/B30-10A2LJA/B30M-18A2
Sensing distance5mm±10%10mm±10%10mm±10%18mm±10%
Response frequencyDC0.4KHz0.2KHz0.2KHz0.1KHz
AC25Hz25Hz

Detectable objectMetal: Iron, copper, steel, aluminum,nickle etc
Differential travelWithin 1%-10% of the sensing distance
Power supply voltageDC type: DC12-24V;
AC type: AC90-250V  50/60Hz
Current consumptionDC type:8mA/12V, 15mA/24V; AC type:<5mA;
Control outputMax 300mA
Protection circuitDC type: short circuit protection;                                               AC type: surge supprossor

Dimmensions
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance
ModeModelsabcdefg
EmbeddableLJA/B842±0.540±0.5/3.5M8x11215
Non-embeddableLJA/B8M48±0.55
EmbeddableLJA/B1252±0.545±0.5/4M12x11721
Non-embeddableLJA/B12M57±0.55
EmbeddableLJA/B1863±0.552±0.5/4M18x12430
Non-embeddableLJA/B18M70±0.58.5
EmbeddableLJA/B3067±0.552±0.5/4.7M30x1.536.2/
Non-embeddableLJA/B30M78±0.512.5



Output Classification
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance

Product Details

Our factory
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance
M12 DC PNP Nc Output Induct Proximity Sensor with 4mm Sensor Distance
