Product Description


Product name : Tycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial Equipment

ItemModelC1K/1KLC2K/2KLC3K/3KL
CapacityVA / Watts1KVA / 0.8KW or 0.9KW2KVA / 1.6KW or 1.8KW3KVA / 2.4KW or 2.7KW
inputNormal voltage220VAC or 110VAC
Turn on Voltage range(115+-5~300+-5)VAC or ( 60+-5-138+-5)VAC
Frequency range40~60Hz(adjustable)40~60Hz(adjustable)40~60Hz(adjustable)
Input power factor>0.99(220VAC,full R load)
GeneratorSupport generator input(Generator rating≥2*UPS rating )
line low loss/comeback220VAC:(110±5)VAC/(195±5)VAC when Load≤55%,   110VAC:(60±3)VAC/(65±3)VAC when load≤40%
220VAC:(130±5)VAC/(195±5)VAC when56%< Load≤65%,   110VAC:(60±3)VAC/(75±3)VAC when40%< load≤50%
220VAC:(150±5)VAC/(195±5)VAC when66%< Load≤70%,   110VAC:(70±3)VAC/(75±3)VAC when50%< load≤60%
220VAC:(160±5)VAC/(195±5)VAC when71%< Load≤90%,   110VAC:(70±3)VAC/(85±3)VAC when60%< load≤70%
220VAC:(185±5)VAC/(195±5)VAC when Load>90%,   110VAC:(90±3)VAC/(95±3)VAC when load>70%
OutputVoltage range200VAC/208VAC/220VAC/230VAC/240VAC/110VAC/120VAC, need confirm before order
Frequency range50Hz or 60HZ+-0.2Hz(Battery mode)
Wave formPure Sine Wave
Transfer time0 ms, Between Line mode and Bat mode
Transfer time: 4ms (typical 2.5ms), line Mode and bypass mode
Distortion≤4%,Full linear load≤4%,Full linear load≤4%,Full linear load
Degree of distortion≤7%,Full nonlinear  load≤7%,Full nonlinear  load≤7%,Full nonlinear  load
Overload capacity<105% warning only, <125% 30s ; <150% 20s,>150%, 300MS to bypass
Load peak ratio3:1(max)
Standard Modes C1K-3KBattery TypeMaintenance free valve regulated lead acid (VRLA) battery
Battery voltage24VDC or 36VDC48VDC or 72VDC72VDC or 96VDC
Internal Battery2*7AH(9AH) or 3*7AH4*7AH(9AH) or 6*7AH or 8*7AH6*7AH(9AH) or 8*7AH
Recharge time5 hours to 90%capacity
Charge Current1A1A1A
Long backup ModeC1K-3KLBattery bank36VDC, External72VDC,External96VDC,External
Charge Current5Amp,Max 7Amp5Amp,Max 7Amp5Amp,Max 7Amp
DisplayLED ModeLoad level / Battery level / Battery mode / Line mode / Inverter , Bypass ,Over load , Fault
LCD Modeinput output HZ/VAC, Bat %/VDC, Load % and VA/Watts,Temp.LCD For input output HZ/VAC, Bat %/VDC, Load % and VA/Watts,Temp. LED for line,bat, Inverter, Bypss
Audible AlarmBattery ModeBeeping every 4 seconds (re-settable) and every second when battery low
OverloadBeeping twice every second
FaultBeeping Continuously
Bettery low/charger faultBeeping every 1 second
Bypass modeBeeping every 2 min
L/N inverseBeeping every 2 min
CommunicationsRS-232/USB InterfaceWith monitoring software
Working EnvironmentSurge protectionRJ-45  I/O port available for network or Fax/Modem
Working temperature- 20ºC~40ºC
Humidity0-95% non-condensing
Product sizeWxDxH (mm)395 x 220 x 430mm460 x 250 x 530mm460 x 282 x 570mm
PCS/CTN 211
N/W, CTN  XG1-3KKg19/23  (base on 7AH)19/23/28 (base on 7AH)24/28 (base on 7AH)
N/W, CTN  XG1-3KL 121212
G/W, CTN XG1-3KKg21/2521/25/3025/30
G/W, CTN XG1-3KL 151414
REMARKXG*K --- Standard Type Internal battery, XG*KL      Long Time Type,External battery


Tycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial EquipmentTycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial EquipmentTycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial EquipmentTycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial EquipmentTycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial EquipmentTycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial Equipment


Certifications

Tycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial Equipment

Packaging & Shipping



Tycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial Equipment

Company Profile



Tycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial EquipmentTycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial Equipment

Our Advantages



Tycorun Industrial Online UPS for Financial & Security, Postal & Telecom, Large Internet Computer, Medical & Health, Industrial Equipment

FAQ



Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?
A. Sample needs 5-10 days, mass production time needs 3-5 weeks, it depends on order quantity.

Q3. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc
for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?
A. We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.

Q5. How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.

Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Contact us for more details about Price, Packing, Shipping and Discount.
